A20
The A20 is Menzi Muck's smallest walking excavator — hydrostatic two-wheel drive, removable plug-in axles and a mechanically telescopic stabiliser, sized for helicopter transport from a starting weight of 2,000 kg.
- Hydrostatic two-wheel drive via the two large wheels, up to 2.6 km/h
- Two removable plug-in axles with wheels
- Mechanically telescopic stabilisers
- Weight: from 2’000 kg
Technical data
| Engine | Kubota Diesel engine — 15.8 kW / 21 PS |
|---|---|
| Displacement | 1,123 ccm |
| Electrical system | 12 V |
| Alternator | 1.0 kW |
| Working pump | (info to come) |
| Smallest swivelling radius | 1,750 mm |
| Swivelling speed | 9 U/min. |
Overview
The A20 is Menzi Muck’s lightest walking excavator, built for deployment on almost any terrain, including small spaces and ground that is hard to reach. It runs on two removable plug-in axles with wheels and a mechanically telescopic stabiliser, driven by hydrostatic two-wheel drive through its two large wheels at up to 2.6 km/h. Its compact size and light weight suit helicopter transport to remote or inaccessible sites.
