Konrad Woody Harvester Heads
Konrad's Woody harvester heads in four sizes, from the WH50-1, which cuts up to 550 mm, to the WH65-1 and WH70-1, which cut up to 750 mm for heavy timber.
Endless rotator built in
Every Woody head has Konrad's own endless rotator integrated, and runs on Konrad's KTC 1.0 control system at 24 V.
Read more
Every Woody head has Konrad's own endless rotator integrated, and runs on Konrad's KTC 1.0 control system at 24 V.
Five delimbing knives
Four flexible delimbing knives and one static knife on every head, with four feed rollers on the WH60-1, WH65-1 and WH70-1 and three on the WH50-1.
Read more
Four flexible delimbing knives and one static knife on every head, with four feed rollers on the WH60-1, WH65-1 and WH70-1 and three on the WH50-1.
A second saw as an option
The main saw has a hydraulic chain tensioner and a .404" chain. A second, smaller saw is optional: a top saw on the WH50-1, WH60-1 and WH70-1, a plunge saw on the WH65-1.
Read more
The main saw has a hydraulic chain tensioner and a .404" chain. A second, smaller saw is optional: a top saw on the WH50-1, WH60-1 and WH70-1, a plunge saw on the WH65-1.
Konrad Woody WH50-1 Harvester Head
- Cuts up to 550 mm, delimbs 40–550 mm
- 3 feed rollers, 32 kN feed force
- 1,030 mm grapple opening
- Integrated Konrad endless rotator and KTC 1.0 control
- Optional top saw, cutting up to 300 mm
Konrad Woody WH60-1 Harvester Head
- Cuts up to 680 mm, delimbs 40–650 mm
- 4 feed rollers, 35 kN feed force
- 1,200 mm grapple opening
- Integrated Konrad endless rotator and KTC 1.0 control
- Optional top saw, cutting up to 320 mm
Konrad Woody WH65-1 Harvester Head
- Cuts up to 750 mm, delimbs 40–650 mm
- 4 feed rollers, 40 kN feed force
- 1,350 mm grapple opening
- Integrated Konrad endless rotator and KTC 1.0 control
- Optional plunge saw, cutting up to 320 mm
Konrad Woody WH70-1 Harvester Head
- Cuts up to 750 mm, delimbs 90–750 mm
- 4 feed rollers, 37 kN feed force
- 1,260 mm grapple opening
- Integrated Konrad endless rotator and KTC 1.0 control
- Optional top saw, cutting up to 350 mm
