Pfanzelt Cable Winches
Pfanzelt's geared cable winches, from the S-line for smaller tractors to the Profi range for professionals, plus quick-fit, recovery and vehicle winches.
Pfanzelt MySelf Front-Mounted Recovery Winch
- 50 kN of pull on the bottom cable layer
- Quick-coupling 3-point mounting, on or off in minutes
- Hydraulically driven, worm gear in an oil bath
- Jaw clutch for rapid cable payout
- As a compact unit or in a front stacking shield
Pfanzelt Profi Geared Cable Winches
- Single-drum sizes from 61 to 102 kN, double-drum from 2 × 60 to 2 × 102 kN
- Constant pull on the P163K, P173K and P273K
- Cable distribution, cable infeed brake and PPS controller as standard
- PHS control for short reaction times, HBC wireless control
- Options include a hydraulic folding shield and an auxiliary winch
Pfanzelt Quick-Fit and Fixed Cable Winches
- Single drum (SW0258) or double drum (SW0306, SW0308)
- Winch and sprag bearing on one frame, so the tractor carries little strain
- Independent oil supply via a radial piston pump
- HBC patrol forest radio system as standard
- Mounted or removed in minutes, alone or with a loading crane
Pfanzelt S-line Geared Cable Winches
- Three sizes, S150, S160 and S172, with 50 to 72 kN of pull
- Wireless control as standard, with engine speed adjustment
- Pfanzelt PPS precision controller, adjustable in three stages
- Cable drum in line with the pull, for easy cable payout
- Options from a cable infeed brake to wider stacking shields
Pfanzelt Vehicle-Mounted Cable Winches
- Lifting and pulling forces from 30 to 160 kN
- Hydraulic-motor or mechanical drive, largely maintenance- and wear-free
- Modular: drum widths matched to the cable length, and combinable
- Options: cable payout, electronic pull monitoring, wireless control
- For fire, rescue, military, construction and utility vehicles
