Pfanzelt MySelf Front-Mounted Recovery Winch
The Pfanzelt MySelf is a hydraulically driven front-mounted recovery winch on a quick-coupling 3-point mounting, for recovering vehicles and equipment in farming, forestry and land management, with 50 kN of pull.
- 50 kN of pull on the bottom cable layer
- Quick-coupling 3-point mounting, on or off in minutes
- Hydraulically driven, worm gear in an oil bath
- Jaw clutch for rapid cable payout
- As a compact unit or in a front stacking shield
Overview
In farming, forestry and land management, a cable winch is often needed to recover a vehicle or a piece of equipment. The MySelf front-mounted recovery winch is designed for that job: a hydraulically driven winch on a quick-coupling 3-point mounting, so it can be fitted for a recovery and removed again in minutes, with secure locking.
Two versions
The BW 0105 is the compact unit, with a 1,010 mm shield and a weight of approx. 200 kg with its cable. The same winch is also available in a front stacking shield, 1,600 mm wide.
Cable and clutch
Both run a 12 mm high-density forestry cable, 50 m long, with a jaw clutch for rapid cable payout and a low loss of pull from the bottom to the top cable layer.
Sizes in this range
| Designation | Traction, lower cable layer | Traction, upper cable layer | Cable | Clutch for rapid payout | Average cable speed at 80 l/min | Shield width | Weight with cable |
|---|---|---|---|---|---|---|---|
| BW 0105 | 50 kN | 35 kN | 12 mm × 50 m, high-density forestry cable | Jaw clutch | 10.1 m/min | 1,010 mm | approx. 200 kg |
| BW 0105, in a front stacking shield | 50 kN | 35 kN | 12 mm × 50 m, high-density forestry cable | Jaw clutch | 10.1 m/min | 1,600 mm | approx. 1,000 kg |
